Camera Image Sensor 1/2.8 inch CMOS Effective Pixels 1920 (H) × 1080 (V), 2MP Scanning System Progressive Electronic Shutter Speed PAL: 1/25s–1/100000s NTSC: 1/30s–1/100000s S/N Ratio > 65dB Minimum Illumination 0.01Lux/F1.6, 0Lux white light on Illumination Distance Distance up to 20 m (65.61 ft) Illuminator On/Off Control Auto; manual Illuminator Number 1 Pan/Tilt/Rotation Range Pan: 0°–360° Tilt: 0°–180° Rotation: 0°–360° Lens Lens Type Fixed-focal Mount Type M12 Focal Length 2.8 mm ;3.6 mm Max. Aperture F1.6 ;F1.6 Field of View 2.8 mm: 126.2° × 106° × 56.5° (diagonal × horizontal × vertical); 3.6 mm: 103.6° × 86.9° × 46.3° (diagonal × horizontal × vertical) Iris Type Fixed iris Close Focus Distance 2.8 mm: 0.6 m (1.97 ft); 3.6 mm: 1.2 m (3.94 ft) DORI Distance Lens Detect Observe Recognize Identify 2.8 mm 38.6 m (126.6 ft) 15.4 m (50.5 ft) 7.7 m (26.3 ft) 3.9 m (12.8 ft) 3.6 mm 55.2 m (181.1 ft) 22.1 m (72.5 ft) 11.0 m (36.1 ft) 5.5 m (18.0 ft) Video Frame Rate CVI: PAL: 1080P@25fps; 720P@25fps; NTSC: 1080P@30fps; 720P@30fps; AHD: PAL: 1080P@25fps; NTSC: 1080P@30fps TVI: PAL: 1080P@25fps; NTSC: 1080P@30fps CVBS: PAL: 960H; NTSC: 960H Resolution 1080P (1920 × 1080); 720P (1280 × 720); 960H (960 × 576/960 × 480) BLC BLC/WDR WDR DWDR White Balance Auto; manual Gain Control Auto; manual Noise Reduction 2D NR Smart Light Yes Mirror Off/On Privacy Masking Off/On (8 area, rectangle) Certifications Certifications CE (EN55032, EN55024, EN50130-4,EN60950-1) FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) Port Video Output Video output choices of CVI/TVI/AHD/CVBS by one BNC port Power Power Supply 12V ±30% DC Power Consumption Max 3.0W (12V DC, White Light on) Environment Operating Temperature -40°C to +60°C (-40°F to 140°F); <95% (non-condensation) Storage Temperature -40°C to +60°C (-40°F to 140°F); <95% (non-condensation) Protection Grade IP67 Structure Casing Metal front cover + plastic main body + plastic bracket Camera Dimensions 161.3 mm × 69.7 mm × 70.0 mm (6.35" × 2.75" × 2.75") Net Weight 0.20 Kg (0.44 lb) Gross Weight 0.28 Kg (0.62 lb)
