OPAX NVR-8000-A01S016-C1 16 KANAL NVR 5 MP DESTEK Model No OPAX-A01S016 Operating System Embedded LINUX operating system Video Standard H.265+/H.265/H.264 Intelligent Support IPC Support Various intelligent detection access and linkages such as line crossing, wondering, face, license plate, audio input abnormality, virtual focus and scene change. Image Code Control Image code quality adjustable, variable stream and limited stream selectable Dual Stream Each channel can be set Monitor Image Quality 5MP / 1080P (1920×1080) / 960P (1280×960) / 720P (1280×720) Bandwidth 40Mbps Image Motion Detection Multiple detection areas can be detected per screen and set 6-level sensitivity (IPC required) Playback Resolution 1ch / 4ch / 9ch / 16ch playback Region Cover Every channel can set 4 cover regions (IPC required) Recording Mode Support manual, automatic, dynamic monitoring, alarm triggered video mode (some need IPC support) Backup Way Support hard disk, U disk, USB mobile hard disk, USB burning, network storage and backup Operation Way Mouse Local Login User name and password Recording Storage Local hard disk, network External Ports Video Input 16ch 5MP H.265+/H.264 IP camera Video Output 1ch VGA+1ch HDMI Network Port 1 x RJ45,10M/100M adaptive Ethernet port USB Port 2 x USB 2.0 ports (rear panel) HDD HDD Port 1 x SATA HDD Port Max Capacity 8TB Max. Phone Monitoring Support iPhone, Windows Mobile, BlackBerry, Symbian, Android Power Supply 12V 2A Power Consumption ? 25 (without hard disk) Operating Temperature -10°C~+55°C Working Humidity 10%-90% Dimensions Device: 260×220×43mm Packing: 355×255×88.5mm
