Hardware

Interfaces

• 10/100BASE-TX WAN port

• 8 10/100BASE-TX LAN ports

• USB 2.0 port

LEDs

• Power

• Internet

• WLAN

• USB

• 8 LAN LEDs

• WPS

Buttons

• RESET button to restore factory default settings

• WPS button to set up secure wireless connection

Antenna

• Two external fixed antennas (2dBi gain)

MIMO

• 2 x 2

Power connector

• Power input connector (DC)

WAN connection types

• LTE

• 3G

• PPPoE

• IPv6 PPPoE

• PPPoE Dual Stack

• Static IP / Dynamic IP

• Static IPv6 / Dynamic IPv6

• PPPoE + Static IP

• PPPoE + Dynamic IP

• PPTP/L2TP

• PPTP/L2TP + Static IP

• PPTP/L2TP + Dynamic IP

Network functions

• DHCP server/relay

• DHCPv6 server (Stateful/Stateless), IPv6 prefix delegation

• DNS relay

• Support of DNSv6 AAAA records

• Dynamic DNS

• Static IP routing

• Static IPv6 routing

• IGMP Proxy

• RIP

• Support of UPnP IGD

• Support of VLAN

• WAN ping respond

• Support of SIP ALG

• Support of RTSP

• WAN reservation

Firewall functions

• Network Address Translation (NAT)

• Stateful Packet Inspection (SPI)

• IP filter

• IPv6 filter

• MAC filter

• URL filter

• DMZ

• Prevention of ARP and DDoS attacks

• Virtual servers

• Built-in Yandex.DNS web content filtering service

VPN

• IPSec/PPTP/L2TP/PPPoE pass-through

USB interface functions

• USB modem

  - Auto connection to available type of supported network (4G/3G/2G)¹

  - Auto configuration of connection upon plugging in USB modem²

Enabling/disabling PIN code check, changing PIN code³

• USB storage

  - File browser

  - Print server

  - Access to storage via accounts

  - Built-in Samba server

  - Built-in FTP server

  - Built-in DLNA server

  - Built-in Transmission torrent client; uploading/downloading files from/to USB storage

Management

• Local and remote access to settings through TELNET/WEB (HTTP)

• Multilingual web-based interface for configuration and management

• Notification on connection problems and auto redirect to settings

• Firmware via web-based interface

• Automatic notification on new firmware version

• Saving/restoring configuration to/from file

• Support of remote logging

• Automatic synchronization of system time with NTP server and manual time/date setup

• Ping utility

• Traceroute utility

• TR-069 client

Standards

• IEEE 802.11b/g/n

Frequency range

• 2400 ~ 2483.5MHz

Wireless connection security

• WEP

• WPA/WPA2 (Personal)

• МАС filter

• WPS (PBC/PIN)

Advanced functions

• WMM (Wi-Fi QoS)

• Information on connected Wi-Fi clients

• Advanced settings

Wireless connection rate

• IEEE 802.11b: 1, 2, 5.5, and 11Mbps

• IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, and 54Mbps

• IEEE 802.11n: from 6.5 to 300Mbps (from MCS0 to MCS15)

Transmitter output power

The maximum value of the transmitter output power depends upon the radio frequency regulations applied in your country

• 802.11b (typical at room temperature 25 °C)

18dBm (+/-1.5dB) at 1, 2, 5.5, 11Mbps

• 802.11g (typical at room temperature 25 °C)

17dBm (+/-1.5dB) at 6, 9, 12, 18Mbps

16dBm (+/-1.5dB) at 24, 36Mbps

14dBm (+/-1.5dB) at 48, 54Mbps

• 802.11n (typical at room temperature 25 °C)

16dBm (+/-1.5dB) at MCS0/1/2/3/4/8/9/10/11/12

14.5dBm (+/-1.5dB) at MCS5/13

12.5dBm (+/-1.5dB) at MCS6/14

8.5dBm (+/-1.5dB) at MCS7/15

Receiver sensitivity

• 802.11b (typical at PER = 8% (1000-byte PDUs) at room temperature 25 °C)

-89dBm at 2Mbps

-83dBm at 11Mbps

• 802.11g (typical at PER = 10% (1000-byte PDUs) at room temperature 25 °C)

-82dBm at 6Mbps

-81dBm at 9Mbps

-79dBm at 12Mbps

-77dBm at 18Mbps

-74dBm at 24Mbps

-70dBm at 36Mbps

-69dBm at 48Mbps

-65dBm at 54Mbps

• 802.11n (typical at PER = 10% (1000-byte PDUs))

HT20

-82dBm at MCS0

-79dBm at MCS1

-77dBm at MCS2

-74dBm at MCS3

-70dBm at MCS4

-66dBm at MCS5

-65dBm at MCS6

-64dBm at MCS7

HT40

-79dBm at MCS8

-76dBm at MCS9

-74dBm at MCS10

-71dBm at MCS11

-67dBm at MCS12

-63dBm at MCS13

-62dBm at MCS14

-61dBm at MCS15

Modulation schemes

• 802.11b: DQPSK, DBPSK, DSSS, CCK

• 802.11g: BPSK, QPSK, 16QAM, 64QAM, OFDM

• 802.11n: BPSK, QPSK, 16QAM, 64QAM with OFDM

Physical Parameters

Dimensions

• 230.5 x 151.5 x 34 mm (9.07 x 5.96 x 1.34 in)

Weight

• 407 g (0.9 lb)

Operating Environment

Power

• Output: 5V DC, 2.5A

Temperature

• Operating: from 0 to 40 °C

• Storage: from -20 to 65 °C

Humidity

• Operating: from 10% to 90% (non-condensing)

• Storage: from 5% to 95% (non-condensing)

Delivery Package

• Router DIR-632

• Power adapter DC 5V/2.5A

• Ethernet cable
